薄板にされた反射45m/Min絶縁ガラスの生産ライン

薄板にされた反射45m/Min絶縁ガラスの生産ライン
Laminated Reflective 45m/Min Insulating Glass Production Line
薄板にされた反射45m/Min絶縁ガラスの生産ライン 薄板にされた反射45m/Min絶縁ガラスの生産ライン 薄板にされた反射45m/Min絶縁ガラスの生産ライン 薄板にされた反射45m/Min絶縁ガラスの生産ライン 薄板にされた反射45m/Min絶縁ガラスの生産ライン

大画像 :  薄板にされた反射45m/Min絶縁ガラスの生産ライン

商品の詳細:
起源の場所: 中国
ブランド名: Lijiang
証明: CE
モデル番号: LJZK 2535
お支払配送条件:
最小注文数量: 1セット
価格: 48000-66000USD/Set
パッケージの詳細: Woodencaseのect
受渡し時間: 30-40仕事日
支払条件: L/C、D/A、D/P、T/T、ウェスタン・ユニオン、MoneyGram
供給の能力: 10Set/日

薄板にされた反射45m/Min絶縁ガラスの生産ライン

説明
名前: 空の二重ガラスはガラス処理機械設備製造業者を絶縁します 電源: 380V、50HZまたはカスタマイズされる
証明: CE, CE& SGS 空気圧: 0.5~0.8Mpa
ハイライト:

45m/Min絶縁のガラス生産ライン

,

薄板にされた絶縁のガラス生産ライン

,

45m/Min二重ガラスのガラス機械

Hollow double glazing insulate glass processing machine equipment manufacturer

Insulation glass machine can complete the following functions: Glass cleaning, aluminum frame placement, ordinary double glass, three ordinary glasses, shaped glass and double double glass press.

Insulation glass machine is special equipment in the manufacture of aluminum strip insulation glass, which has the advantages of small footprint, high efficiency, reliable performance and easy maintenance.

薄板にされた反射45m/Min絶縁ガラスの生産ライン 0薄板にされた反射45m/Min絶縁ガラスの生産ライン 1薄板にされた反射45m/Min絶縁ガラスの生産ライン 2

glass production line  insulating glass machine   vertical glass washing machine insulated glass equipment

Advantage:

1, European design concept, easy and intelligent operation;

2, World famous brand of main ingredients ensure stable operation and long service life;

3, Designed for high quality glass processing such as reflective glass, Low-E glass, tempered glass and laminated glass.

4, large glass processing scale, various models and customization available;

5, large output capacity, 1,000pcs output in one working day;

6, workable for double layer, triple layer, stepped sheet and abnormal shape insulation glass;

7, automatic argon air gas filling during the glass sheet assembly process;

8, PLC control system, touch screen operation;

Electrical parameters

NAME ORIGIN BRAND
Transfer motor Germany SIEMENS
Brush motor Germany SIEMENS
Servo motor Germany SIEMENS
PLC Germany SIEMENS
Low voltage electrical appliance Germany SIEMENS
Frequency converter Germany SIEMENS
Micro Switch Taiwan TEND
Button and indicator light France SCHNEIDER
Touch screen Taiwan WEINVIEW
Intermediate relay Japan OMRON
Water pump China LINGXIAO
Guide Taiwan HIWIN
Pneumatic Components Taiwan AIRTAC
Electric gauge China MIRAN
Photoelectric switch Korea AUTONICS
JINAN LIJIANG AUTOMATION EQUIPMENT CO.,LTD



Power Supply 380V,50HZ or customized
Total Power 40 KW
Washing Speed 2-10m/min
Max. working speed 45m/min
Min.Glass size 450*280mm
Max. Glass size

2500*3200

2500*4500(second pressing)

Washing glass thickness 3-15mm
Max. Insulating glass thickness 50mm
Weight 8000kg
Dimension (L*W*H) 23600*3500*3700mm

薄板にされた反射45m/Min絶縁ガラスの生産ライン 3薄板にされた反射45m/Min絶縁ガラスの生産ライン 4

薄板にされた反射45m/Min絶縁ガラスの生産ライン 5

Company Information

About Our Company
Founded in 2009, Kation-Tech specializes in R&D, production and sales of Insulating glass machinery and related auxiliary equipment for the glass deep processing industry and the door and window construction industry. Has the professional processing basis of insulating glass machinery, aluminum-plastic windows & doors machinery and the related auxiliary materials, etc. In this way, we provide the most comprehensive glass processing solution and windows & doors solution for domestic and foreign customers well. Until 2019, we exported glass machines and materials to America, South America, Europe, the Middle East, India and so on, nearly 30 countries and regions. We have established a perfect international business relationship with 10 powerful agents and made an endeavor together to build a famous international brand to the world. Kation-Tech, with craftsmanship, profession and honesty, wins the future with you together!
